Electric Metals drills 1.46 m of 46.3% Mn at Emily

2023-10-31 11:09 ET - News Release

Mr. Gary Lewis reports

ELECTRIC METALS ANNOUNCES FINAL ASSAYS FROM THE EMILY MANGANESE PROJECT WITH HIGH-GRADE MANGANESE DRILL INTERSECTIONS UP TO 64.68 METERS CONTAINING ZONES OF UP TO 46.3% MN (59.8% MNO)

Electric Metals (USA) Ltd. has released the final assay results from the recent drilling program at the high-grade Emily manganese project in Minnesota, United States.

Highlights:

  • Assay results from the final seven drill holes confirm that thick intersections of high-grade manganese extend along trend for more than 1,100 meters (3,609 feet), containing grades up to 46.3% Mn in individual samples. Results include[1]:
    • 46.30% Mn (59.78% MnO) over 1.46 meters within 16.62% Mn over 20.60m
    • 44.60% Mn (57.59% MnO) over 1.43 meters within 12.31% Mn over 32.46m
    • 42.60% Mn (55.01% MnO) over 0.76 meters within 12.85% Mn over 64.68m
    • 41.10% Mn (53.07% MnO) over 1.43 meters within 25.63% Mn over 5.61m
  • The drilling program has demonstrated excellent continuity of high-grade manganese, and mineralization has not been closed by drilling along trend or at depth.
  • Analytical data confirms that sulfur (S), which is assayed in every sample, is seldom above detection (0.001%).

Previously reported results from the first twenty diamond drill holes of the program (refer announcements dated 27 th June 2023, 13 th July 2023, 24 th August 2023 and 21 st September 2023) described continuity of thick intervals of more than 30% manganese with a northerly dip and east-west strike direction.

New results reported in this announcement are for an additional seven drill holes located on 100-meter collar spacing (23047, 23048, 23049, 23050, 23052, 23053 and 23054) which confirm that high-grade, thick manganese intervals encompass at least 1,100 meters along an east-west trend (Table 1 and Figures 1-4) and show that the high-grade manganese oxide mineralization (manganite) has not been closed at depth or along trend.

New Assay Results

All seven drill holes intersected high-grade manganese with drilled intervals (approximate true thickness) of more than 20 meters (Table 1). Intervals with manganese contents of more than 44% Mn were intercepted in holes 23047, 23050 and 23053 however, all holes contain conspicuous intervals of more than 30% Mn within mineralized zones (5% Mn cut-off) of up to 64.68 meters thick. Importantly, the mineralization has excellent continuity in both thickness and tenure both along trend (Figure 2) and down down-dip (Figures 3 and 4).

Data Summary

Analytical data on quartered PQ sized drill core from the 27 completed diamond drill holes at Emily comprise a total of 2,156.6 meters (7,075.5 feet) of drill core (Table 2). Overlying rocks, host rock and underlying strata without visible mineralization were not sampled and uncut drill core from these intervals are kept on site for ongoing geology study. In total, 417 samples exceeded 10% Mn and these showed an average grade of 24% Mn which is largely contained within the dark grey to black manganese oxide mineral manganite (MnO(OH)).

Other major elements in the Mn mineralized rock include iron (Fe) and this ranges from 4.54% Fe to 51.99% Fe. Average iron content is the same for both the high Mn and low Mn sample groups (21.72% Fe) but the distribution shows a trend of lower Iron content in manganese samples with more that 25% Mn (Figure 5).

Quartz (SiO 2 ) is the other main component of the mineralization and ranges up to 78.1% in the mineralized samples. Like Fe, there is a distinct decrease in quartz component with increasing manganese (Figure 5) and only a few samples with more than 25% Mn have greater SiO 2 than Mn content. Typically, very high-grade Mn samples have low SiO 2 content (Figure 6).

Copper, nickel and lead do not occur in the mineralization. Contents of these for each assayed interval are commonly less than detection (0.001%) and seldom more than 0.05%. Similarly, sulfur (S), also assayed for every sample, is seldom above detection (0.001%) and only ten samples (1.3% of analyses) contain more than 0.05% sulfur. There is unlikely to be concerns over metal contamination and acid generation from sulfides in any future development.

Metallurgical test work on composited samples collected from drill holes completed in the first part of the program is progressing at Kemetco Research Inc in Vancouver and results from this work will assist in manganese separation and concentration parameters of different ore types and ratios. Metallurgical investigations are expected to continue into 2024.

Geological Consultants, Big Rock Exploration have managed the drilling program and geology work and are currently near completion of a geological model for the deposit. Forte Dynamics Inc have commenced a NI43-101 resource update, and this is expected to be completed in late 2023.

Gary Lewis, Group CEO of EML commented on these final Emily results: "The thickness and grades of manganese have continued to the last drill hole, and we remain confident that we have substantially added to both the size and the average grade of the deposit."

"The drilling program has been undertaken at the highest standard and achieved better outcomes than anticipated. I congratulate and thank our technical team, the drillers and all of the support crew who have worked tirelessly during the program."

"We are now focused on advancing the metallurgical tests and finalizing a new NI 43-101 mineral resource estimate, which remains on track for delivery late this year. Environmental baseline data review and field studies are now underway and together with our social engagement programs, will form an important base for future project planning."

"The strategic value of US-domiciled critical mineral projects such as the Emily Manganese Project has never been greater as the world transitions to clean energy and as domestic sources of supply becomes more important in an increasingly uncertain global landscape".Figure 6. High-grade manganese in drill hole 23057. Sample 798734 (91.4m to 92.17m; 299.9-302.4 feet) contains 44.0% Mn, 10.69% Fe and 0.79% SiO2.

Qualified Person

The scientific and technical data contained in this news release was reviewed and approved by Ian James Pringle PhD, who is a Qualified Person under National Instrument 43-101 Standards of Disclosure for Mineral Projects.

About Electric Metals (USA) Limited

Electric Metals (USA) Limited (TSXV: EML) (OTCQB: EMUSF) is a U.S.-based mineral development company with manganese and silver projects geared to supporting the transition to clean energy. The Company's principal asset is the Emily Manganese Project in Minnesota, which has been the subject of considerable technical studies, including a National Instrument 43-101 Technical Report - Resource Estimate, with over US$26 million invested to date. The Company's mission in Minnesota is to become a domestic U.S. producer of high-purity, high-value manganese metal and chemical products for supply to U.S. energy, technology and industrial markets. With manganese playing a critical and prominent role in lithium-ion battery formulations, and with no current domestic supply or active mines for manganese in North America, the development of the Emily Manganese Project represents a significant opportunity for America, the State of Minnesota and for the Company's shareholders. In addition, the Company owns and operates the Corcoran Silver-Gold Project and the Belmont Silver Project in Nevada, with the former also having been the subject of a National Instrument 43-101 Technical Report - Resource Estimate.
